| 260 Horsepower Bulldozer Performance Parameters | |||
| Model | HW26DE | ||
| Performance Parameters | Operating Weight (kg) (excluding ripper) | 24200 | |
| Minimum Turning Radius (mm) | 3300 | ||
| Ground Pressure (kpa) | 0.062 | ||
| Engine | Engine Model | Weichai WP12G280E304 | |
| Power/Speed (Kw/rpm) | 206/1900 | ||
| Dimensions | Overall Dimensions (mm) | 5920×3642×3460 | |
| Chassis System | Ground Clearance (mm) | 405 | |
| Track Center Distance (mm) | 2000 | ||
| Track Width (mm) | 560/610/660 | ||
| Number of Track Plates (per side) | 41 | ||
| Pitch (mm) | 216 | ||
| Number of Rollers (per side) | 2 | ||
| Number of Support Rollers (per side) | 7 | ||
| Fuel Tank Capacity | Fuel Tank (L) | 450 | |
| Hydraulic Tank (L) | 110 | ||
