Power: 380KW
Engine Model: VOLVO PENTA TAD 1650VE-B
Operating Weight(with ripper): 54000 KG
| ENGINE | Diesel engine | VOLVO PENTA TAD 1650VE-B |
| Diesel engine Rated power | 380kW | |
| Maximum power | ||
| ISO 9249 | 380 kW | |
| Rated speed | 1,900 rpm | |
| Displacement | 16.12I/984 in3 | |
| Design | 6 cylinder in-line engine,water-cooled,turbocharged,water -to-air intercooler | |
| Injection system | Direct fuel injection,electronic control unit pump | |
| Lubrication | Pressurised lube system,engine lubrication guaranteed for inclinations up to 30° | |
| Operating voltage | 24V | |
| Alternator | 110A | |
| Starter | 7kW/9.4HP | |
| Batteries | 4x 75 Ah /12 V | |
| Air cleaner | Dry-type air cleaner with pre-cleaner,main and safety elements | |
| Forward speed | 1st gear: 4.3 km/h 2nd gear: 7.7 km/h 3rd gear: 12.8 km/h | |
| Cooling system | Combi radiator,comprising radiators for water and charge air.Hydrostatic fan drive | |
| winch | Maximum pulling force | 50 tons |
| Drum diameter | 660 mm | |
| TRAVEL DRIVE CONTRO | Transmission system | Infinitely variable hydrostatic travel drive,independent drive for each track |
| Travel speed | Continuously variable | |
| Forward and reverse | 0-11.0 km/h/6.8mph *Travel speed ranges can be set on the travel joystick(speed preset function) | |
| Electronic control | The electronic system automatically adjusts travelspeed and drawbar pull to match changing load conditions | |
| Steering | Hydrostatic | |
| Service brake | Hydrostatic(self-locking),wear-free | |
| Parking brake | Multi-disk brake,wear-free,automatically applied with neutral joystick position | |
| Cooling system | Hydraulic oil cooler integrated in combi radiator,hydrostatic fan drive | |
| Filter system | Micro cartridge filters in replenishing circuit*2 | |
| Final drive | Reducer with planetary gear | |
| Final drive | single joystick for all travel and steering functions. | |
| HYDRAULICS | Hydraulic system | Load sensing(demand-controlled)Swash plate |
| pump system | piston pump | |
| Pump flow max. | 320 I/min/84.5 gpm | |
| Pressure limitation | 230 bar/3336 psi | |
| Control valve | 2 segments,expandable to 42 | |
| Filter system | Returm filter in hydraulic oil tank | |
| Control | one joystick for allblade functions,one joystick forall iper functions | |
| OPERATOR′S | Cab | Resiliently mounted cab with positive pressure ventilation,can be tilted with hand pump 43°to the rear.With integrated ROPS and FOPS |
| Operator's seat | Air-suspended comfort seat,fully adjustable,belt-warning,cushion heater | |
| Monitoring | Touch screen:display of curent machine information,automatic monitoring of operating conditions.Individual setting of machine parameters | |
| UNDERCARRIAGE | Design | Undercarriage with K-bogie suspension |
| Mounting | Via separate pivot shafts and equalizer bar | |
| Track chains | Lubricated, single-grouser shoes, tensioning via a steel spring and grease tensioner | |
| Links, each side | 45 | |
| Track rollers, each side | 8 | |
| Carrier rollers, each side | 1 | |
| Sprocket segments,each side | 5*6 teeth | |
| Track shoes, standard | 610 mm/24 | |
| Track shoes, optional | 660mm/26 | |
| REFILL CAPACITIE | Fuel tank | 1200L |
| Cooling system | 90L | |
| Engine oil, with filter | 50 L | |
| Hydraulic tank | 500L | |
| Final drive, each side | 50 L |
