Rated lift weight: 3500kg
Rated lifting height: 3000-7000mm
Overall weight:4200/4500kg
Off-road forklifts, also known as field forklifts, are material handling equipment designed for complex working environments. In addition to airports, docks, and stations, they are also suitable for field sites and material distribution centers with harsh road conditions such as mines and farms. With its powerful power system and special off-road tires, it has excellent maneuverability, strong off-road performance and high reliability. It can efficiently complete cargo loading and unloading and handling tasks on unpaved roads such as muddy and gravel roads, greatly improving the efficiency and stability of field operations.
Machine detailed parameters
| HWC-35A | |||||
| Model | HWC-35A | HWC-35A Simple shed | HWC-35A Short model | HWC-35A Rear ariculate | |
| Dimensions | 4200*1850*2700 | 3600*1850*2150 | 3800*1850*2300 | 3700*1850*2350 | mm |
| Engine brand | Huajie / Yunnei / Quanchai( optional) | ||||
| Engine model | 490 | 493 | 490 | 493 | |
| Engine power | 40 | 36.8 | 42 | 36.8 | kw |
| Fork length | 1220 | mm | |||
| Rated lift weight | 3500 | kg | |||
| Rated lifting height | 3000-7000 | mm | |||
| Turning radius | 3500 | 3200 | 3200 | 3200 | mm |
| Platform ground clearance | 250-350 | mm | |||
| Front ground clearance | 250-350 | mm | |||
| Mast width | 16cm widened poral frame | cm | |||
| Axle | Small wheel-side cast steel bridge | ||||
| Tyre | Medium20.5/70-16 | Medium23.5/70-16 | |||
| Gradeability | ≤ 38° | ||||
| Drive type | 4-wheel drive | ||||
| Gearbox | 265 Double high and low speed torque converer | ||||
| Overall weight | 4200 | 4200 | 4200 | 4500 | kg |
