Main parameters
| Model | HW936 |
| Engine | Cummins |
| Power (KW) | 191 |
| Drill rod type (㎜) | φ76*3000 |
| Drilling diameter (㎜) | φ90-115 |
| Maximum working torque (N.m) | 2700 |
| Rotation speed (rpm) | 70-150 |
| Thrust force (kN) | 15 |
| Lifting force (kN) | 25 |
| Thrust mode | Motor+Chain |
| Leveling angle | ±10° |
| Travel speed (km/h) | 1.5-3 |
| Climbing ability | 30° |
| Total weight (Kg) | 9400 |
| Transport dimensions (㎜) | 8800*2300*2600 |
| 空压机 | 16/16 |
