Machined etailed parameters
| HWQC10T-3 | ||
| Truck brand | Dongfeng F5(other truck brand can be customi zed) | |
| Chassis | Driving type : 2X8, Left hand drive (Right hand drive type can be customized) | |
Color is optional | ||
| Vehicle Main Dimensions | Overall size (LxWxH) | 11950x2550x3950mm |
| Wheel base | 5850x1350mm | |
| Cargo Body | 8500*2450*550mm | |
| Weight in KGS | GVW | 25000 kg |
| Rated cargo capacity | 12230kg | |
| Front axle loading capacity | 5500 kg | |
| Rear axles loading capacity | 2 x10000 kg | |
| Engine | Engine Model & Power | YUNCHAI YCS06270-60 270HP (199kw) |
| Horse Power | 177kw | |
Max Torque | 1000N. m | |
| Emission standard | Euro V | |
| Max Speed | 90 km/h | |
| Gearbox | Fast 9-Speed gear with high and low speed | |
| Tire | 11.00R20 11 pieces including one spare tire | |
| *Warranty Period | 1. Provide one-year warranty on all exported machines. During the warranty period, if the machine is mechanically damaged due to quality problems. We will provide DHL or Fedx replacement original parts for free to keep the machine working efficiently. (But excluding any damage caused by improper use or abuse, improper storage and operation) 2. Spare parts: Have 6 years of experience in the supply of machines and spare parts. We are working hard to provide original branded spare parts at a low price, fast response and professional service | |
